Factory Welded Steel Superior Empty 50KG LPG Gas Bottle Cylinder in Africa

Product Name

50KG LPG Gas Bottle Cylinder in Africa

Standard

 ISO4706, EN1442 or Others

Cylinder Material

GB6853 Steel Grade HP295 or Equivalent

Test Pressure

34 Bars

Work Pressure

17 Bars

Blasting Pressure

60 Bars

Cylinder Wall Thickness

 About 3.4MM

Tare weight

44.5±0.5KG

Valve

Optional

Relevant Products

 Low pressure regulator, PVC hose, gas stove, cast iron stove

Welding Process As Following:

Circumferential: Automatic Gas Metal Arc Welding, Shielding CO2+Ar

Spud/Bung: Automatic Gas Metal Arc Welding, Shielding CO2+Ar

Heat Treatment: Stress Relieved At 650±20°-11 Minutes

Surface Treatment: Abrasive Blasting With Cleaning Sa2.5 Class Painting

Painting: 1 Coat Power Paint 50-120 Microns or 2 Coats Stoving Alkyd Paint 50-120 Microns

Cylinder Color: Blue

Printing: According to Client’s Content With White Color

Daly LPG Cylinders Advantage:

1. Re-inspection of incoming materials

The manufacture of liquefied gas cylinders is to implement the GB5842-2006 standard. The standard stipulates that the main material of the cylinder must be re-inspected and re-examined before being used. Chemical composition test according to furnace number, mechanical performance test by batch number

Chemical composition: main 5 major elements (spectrum analyzer)

Mechanical properties: tensile strength, yield strength, elongation, bending test

The materials for the cylinder body is HP steel mainly provided by the first class steel factories in China.

2. Better inner quality. We have one more airtight inspection than other manufacturers to ensure that the 100% of the cylinders are not leaking before leave our factory.

3. Better external quality. Plastic powder as the surface protective coating. Wear-resistant, impact resistant and long service life time. Some other manufacturers choose oil paint and it is easy to fall off.

4. Our powder is the first international brand, and the powder has a service life of more than 10 years.

5. During the whole production process, there are 2 airtight inspection in total. One inspection is before the powder cured and another one inspection is after the powder cured. Water pressure test is also added, so the product quality is absolutely guaranteed.

6. The production is strictly in accordance with the standard requirements and the manufacturing process procedures. The most critical of the cylinder products is the welding and the heat treat process. Our welding and heat treatment processes can ensure that the hydraulic blasting and mechanical properties meet the standard requirements. In some small companies, heat treatment simply does not meet the requirement.

7. Our factory has been in this area about 30 years already and most of our colleagues and workers have worked in our factory over 10 years, they are skillful and very professional.

Question 1: Are you the factory or trading company? Can we visit your factory?

A: We are the factory. If available, welcome to visit us.

Question 2: What are the main products for Daly?

A: We Daly mainly supply LPG cylinders, valves and other parts for LPG cylinders.

Question 3:  How about the payment terms and delivery time?

A: Payment terms: 30% as deposit, balance against copy of BL, L/C at sight, TT or discussed again before order.

Delivery time: It usually takess about 10 to 60 days when deposit confirmed. The specific delivery time depends on the items and the quantity of your order.

Question 4:  How about the sample?

A: Samples should be customized for you. Fees for sample and shipping could be discussed before order.

Question 5: How to ensure your cylinder quality?

A: We have ISO9001, BV,CE certificate. and we have been in this field for more than 20 years and ship the goods almost all over the world, especially market in Africa and Southeast Asia.

Question 6 How do your make our business long-term and good relationship?

A:

1. We keep good quality and competitive price to ensure our customers to get good benefit.

2. We respect every customer as our friend and we sincerely do business and make friends with them no matter where they come from.
