About this product
- Materials: Low carbon steel
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
About this product
- Materials: Low carbon steel
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
Product details
| Materials | Low carbon steel |
|---|
From the supplier
HIGH FREQUENCY PIPE MAKING MACHINE
BH45 High-Frequency Welded Pipe Mill Line is designed to produce welded pipes of Ф15～Ф63mm in diameter and 0.5～2.5mm in wall thickness as well as square and rectangular pipes and deformed pipes of the corresponding size. Adopting roll pass design, the production line can manufacture welded steel pipes with good quality machining and high precision assembling
PRODUCE CAPACITY
NO.
ITEM
WORKING RANGE
REMARK
1
Outer diameter.
Φ15mm～Φ63mm
2
Pipe thickness.
δ0.5mm～2.5mm
3
Square tube size
15×15mm～50×50mm
4
Square tube thickness
δ0.5mm～2.0mm
5
Rectangular pipe size
10*20mm～40×60mm
6
Rectangular pipe thickness
δ0.5mm～2.0mm
7
Produce speed
20M/min～110M/min
8
Pipe length
4M～8M
Working flow
Raw material (steel coil) → uncoiling →material accumulating → non-power leveling →mill-forming → high-frequency welding → removing burrs outside of weld seam → cooling → sizing → roughly straightening → fixed length cutting → run-out table
