Intelligent electrostatic sensor
The supplier hasn’t listed a price. We can get their current prices and MOQ.
- Service
- From $29 per supplier (Verify)
- You get
- Phone and video verification, a quote sheet and a written report
- Turnaround
- 3 business days
- Contact details
- Sent to you once your request is confirmed
If we can't reach the supplier within 3 business days, we refund the fee.
Intelligent electrostatic sensor
The supplier hasn’t listed a price. We can get their current prices and MOQ.
- Service
- From $29 per supplier (Verify)
- You get
- Phone and video verification, a quote sheet and a written report
- Turnaround
- 3 business days
- Contact details
- Sent to you once your request is confirmed
If we can't reach the supplier within 3 business days, we refund the fee.
About this product
- Size: 44*33*85mm
- Color: black
- Customized: Customized
- Material: Other
- Certification: Other
- Application: Lab
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
About this product
- Size: 44*33*85mm
- Color: black
- Customized: Customized
- Material: Other
- Certification: Other
- Application: Lab
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
Product details
| Size | 44*33*85mm |
|---|---|
| Color | black |
| Customized | Customized |
| Material | Other |
| Certification | Other |
| Application | Lab |
From the supplier
AP-YV3302 electrostatic sensor uses non-contact vibration capacitive electrostatic detection technology, high-precision automatic detection of static electricity on the surface of objects, monitoring data real-time transmission to the PC, data acquisition and data storage can be achieved. Set the threshold value of static electricity alarm, beyond the threshold value red light alarm.
2.FEATURES: 1. Comfortable in hand and beautiful in shape. 2. Detection distance can be selected by dip switch. 3. detection potential range is wide, high detection accuracy. 4. Alarm threshold can be set, beyond the threshold red light alarm. 5. High-definition, all-round LCD data display terminal. 6. Monitoring data can be transferred to PC in real time. 7. Comfortable operation, easy to use. 3.SPECIFICATION:
No.
Technical specifications
1
Working voltage
DC8-24V
2
Working current
<20mA
3
Vibration
＜1KHz
4
Noise
＜5dB
5
Signal output
RS485
NPN (Collector control, 24/100mA)
6
Communication distance
＜500m
7
Alarm indication
Red light LED
8
Threshold setting
±100V (default)
9
Alarm range
±50→±5000V
10
Detection angle
＜15°
11
Startup stand-by time
5s
12
Infrared control distance
1m
5.CLOSED-LOOP ELECTROSTATIC DETECTION,MONITORING AND ELIMINATION SYSTEM Closed-loop electrostatic detection, monitoring and elimination system Closed-loop electrostatic detection, monitoring and elimination system Closed-loop static monitoring and elimination system consists of detection equipment, elimination equipment, power supply equipment, display equipment and IMS (ionization monitoring system), under the control of the system software, to achieve the real sense of real-time monitoring, data storage, and dynamic display functions, to solve the long-standing record of static monitoring and data collection problems, can be customized according to customer needs to develop, to truly achieve increased productivity and The system can be customized according to the customer's individual needs, and truly achieve increased productivity, efficiency, automatic, intelligent static monitoring.
