About this product
- Size: 1845 x 770 x 1140 mm
- Color: white
- Engine: 4 Stroke
- Starting system: Kick Start and Electric Start
- Certification: Other Certifications
- Seat high: Other Heights
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Others
- Made in: Zhejiang, China
About this product
- Size: 1845 x 770 x 1140 mm
- Color: white
- Engine: 4 Stroke
- Starting system: Kick Start and Electric Start
- Certification: Other Certifications
- Seat high: Other Heights
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Others
- Made in: Zhejiang, China
Product details
| Size | 1845 x 770 x 1140 mm |
|---|---|
| Color | white |
| Engine | 4 Stroke |
| Starting system | Kick Start and Electric Start |
| Certification | Other Certifications |
| Seat high | Other Heights |
| Displacement | 126-250cc |
| Fuel | Gas / Diesel |
| Tank capacity | Other Capacities |
| Cylinder quantity | Other Cylinder Quantities |
Product details
| Size | 1845 x 770 x 1140 mm |
|---|---|
| Color | white |
| Engine | 4 Stroke |
| Starting system | Kick Start and Electric Start |
| Certification | Other Certifications |
| Seat high | Other Heights |
| Displacement | 126-250cc |
| Fuel | Gas / Diesel |
| Tank capacity | Other Capacities |
| Cylinder quantity | Other Cylinder Quantities |
From the supplier
1
Engine
Engine Type
Single-cylinder, 4-valve, Oil cooling, Manual, 4 gears
Displacement
140cc
Bore*Stroke
56mm*57mm
Compression Ratio
9.8:1
Max. Power
8.2/8000 kw/rpm
Max. Torque
10.2/7500 N.m/r/min
Fuel System
Standard Carburetor
Starting
Kick
Transmission
Chain (15T-41T 428H#)
Ignition
CDI
2
Chasis
Frame
Professional design and processed by KAYO
Front shock
735mm, reverse,Non-adjustable
Rear shock
360mm Non-adjustable
Front Braking
Disc Brake
Rear Braking
Disc Brake
Front Wheel Rim
Steel 1.6*17
Rear Wheel Rim
Steel 1.85*14
Front Tyre
17" 70/100-17
Rear Tyre
14" 90/100-14
3
Dimensions and Capacities
Vehicle Size
1780*750*1120mm
Wheelbase
1220mm
Seat Height
855mm
Ground Clearance
290mm
Dry Weight
73kg
Fuel Capacity
5.5 L
Packing Size
1560*380*735 mm
Qty in 20'GP/40”HQ
63 PCS/153PCS
From the supplier
1
Engine
Engine Type
Single-cylinder, 4-valve, Oil cooling, Manual, 4 gears
Displacement
140cc
Bore*Stroke
56mm*57mm
Compression Ratio
9.8:1
Max. Power
8.2/8000 kw/rpm
Max. Torque
10.2/7500 N.m/r/min
Fuel System
Standard Carburetor
Starting
Kick
Transmission
Chain (15T-41T 428H#)
Ignition
CDI
2
Chasis
Frame
Professional design and processed by KAYO
Front shock
735mm, reverse,Non-adjustable
Rear shock
360mm Non-adjustable
Front Braking
Disc Brake
Rear Braking
Disc Brake
Front Wheel Rim
Steel 1.6*17
Rear Wheel Rim
Steel 1.85*14
Front Tyre
17" 70/100-17
Rear Tyre
14" 90/100-14
3
Dimensions and Capacities
Vehicle Size
1780*750*1120mm
Wheelbase
1220mm
Seat Height
855mm
Ground Clearance
290mm
Dry Weight
73kg
Fuel Capacity
5.5 L
Packing Size
1560*380*735 mm
Qty in 20'GP/40”HQ
63 PCS/153PCS
