Lan cable internet cable rj45 computer data patch cable cat5e cat6 cat6a cat7 cat8
The supplier hasn’t listed a price. We can get their current prices and MOQ.
- Service
- From $29 per supplier (Verify)
- You get
- Phone and video verification, a quote sheet and a written report
- Turnaround
- 3 business days
- Contact details
- Sent to you once your request is confirmed
If we can't reach the supplier within 3 business days, we refund the fee.
Lan cable internet cable rj45 computer data patch cable cat5e cat6 cat6a cat7 cat8
The supplier hasn’t listed a price. We can get their current prices and MOQ.
- Service
- From $29 per supplier (Verify)
- You get
- Phone and video verification, a quote sheet and a written report
- Turnaround
- 3 business days
- Contact details
- Sent to you once your request is confirmed
If we can't reach the supplier within 3 business days, we refund the fee.
About this product
- Size: 10
- Color: colorful
- Use: Other
- Shape: FlatOther
- Material: Other
- Operation temperature: -
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea
About this product
- Size: 10
- Color: colorful
- Use: Other
- Shape: FlatOther
- Material: Other
- Operation temperature: -
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea
Product details
| Size | 10 |
|---|---|
| Color | colorful |
| Use | Other |
| Shape | FlatOther |
| Material | Other |
| Operation temperature | - |
| Feature | WaterproofEco-FriendlyOther |
| Finishing | Other |
From the supplier
Product Specifications
Technical specification
Cat6 UTP copper network patch cord for computer device is an ultra-high quality category 6 unshield twisted pai r(utp) molded plenum patch cable.
Utp is accepted for residential and general commercial installation. In SURELINK, you can get true cat6 performance with component certified cat6 patch cables.
Flat cables fit easily between cramped spaces improving the look of your home or office because they are flat and easy to hide.
These flat cables are a perfect fit under carpets, up walls, and even behind furniture.
Material: Bare Copper 99% DC resistance Max.: 93.8 Ω/km Conductor
Construction: Stranded copper 7*0.20 mm Insulation resistance
Min.: 100 MΩ/km Gauge: 23 AWG Dielectric strength: AC-500V
1 min no breakdown Conductor
Nom.O.D: 0.61mm DC resistance unbalance: Max 2% Insulation Material: HDPE Input impedance: 100±15Ω @4-100MHz Sheath
Material: PVC Maximum tension: 110N Sheath
External O.D.: 6.3 ± 0.4 mm Elongation: ≥100 % Sheath
Sheath Color: Red Minimum bending radius: 8x outside diameter Sheath
Plug Housing: Clear polycarbonate,
94V-0 Rate Operating temperature: -20°C to 60°C Sheath
Terminal: Phosphor bronze
3~50U gold plating Weight: 35.7 KGS/1000m
Email:sales@zhsurelink.com
Wechat: surelink2008
WhatsApp: +86 13926923676
https://www.zhsurelink.com
About the supplier
Main products: Lan Cable, UTP CAT6,adss cable,fiber cable,ftth cable,plc splitter,fiber terminal box,ODF,fiber patch cord,fiber pigtail,fiber cabinet,microduct,fiber clamp
- ✓Exhibited at 4 recent Canton Fairs
- ✓Foreign Trade Company
- ✓Founded 2008
- ✓1 certificate on file
- Exhibited at 4 recent Canton Fairs
- Foreign Trade Company
- Founded 2008
- 1 certificate on file
