About this product
- Materials: PA66
- Size: 83*71*18
- Color: Grey
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
About this product
- Materials: PA66
- Size: 83*71*18
- Color: Grey
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
Product details
| Materials | PA66 |
|---|---|
| Size | 83*71*18 |
| Color | Grey |
From the supplier
Function and Feature:
Protection against both overload and short circuit,function of isolation
High short circuit capacity
Contact position indicator
Pin/fork type busbar terminal connecting
35mm DIN rail mounting and screw mounting
Handle can be locked with pad-lock to prevent unwanted operation for safety.
Full range accessories are available.
Technical data
Rated current(In):1,2,3,4,6,10,13,16,20,25,32,40,45,50,63ARate voltage(Un):230/415VAC,400/415VACBreaking capacity:10kARated frequency:50/60HzTripping charateristics:B,C,DNumber of poles:1P,2P,3P,4P,1P+N,3P+NRated impulse withstand voltage(Uimp):4kvElectrical endurance:10000cyclesMechanical endurance:20000cyclesTerminal:pillar typeCable termination:25mm2Torque of screw:2.5NmIP degree:IP20Standards:IEC/EN 60898-1Catalog No. CTN Size:46.5X24X17.5
In(A)B(3-5In)C(5-10In)D(10-20In)QTY/BoxQTY/CTN Model No.Model No.Model No.PCSPCS1A
AUB7H 1P+N B1AUB7H 1P+N C1AUB7H 1P+N D16602AAUB7H 1P+N B2AUB7H 1P+N C2AUB7H 1P+N D26603AAUB7H 1P+N B3AUB7H 1P+N P C3AUB7H 1P+N D36604AAUB7H 1P+N B4AUB7H 1P+N C4AUB7H 1P+N D46606AAUB7H 1P+N B6AUB7H 1P+N C6AUB7H 1P+N D666010AAUB7H 1P+N B10AUB7H 1P+N C10AUB7H 1P+N D1066016AAUB7H 1P+N B16AUB7H 1P+N C16AUB7H 1P+N D1666020AAUB7H 1P+N B20AUB7H 1P+N C20AUB7H 1P+N D2066025AAUB7H 1P+N B25AUB7H 1P+N C25AUB7H 1P+N D2566032AAUB7H 1P+N B32AUB7H 1P+N C32AUB7H 1P+N D3266040AAUB7H 1P+N B40AUB7H 1P+N C40AUB7H 1P+N D4066045AAUB7H 1P+N B45AUB7H 1P+N C45AUB7H 1P+N D4566050AAUB7H 1P+N B50AUB7H 1P+N C50AUB7H 1P+N D5066063AAUB7H 1P+N B63AUB7H 1P+N C63AUB7H 1P+N D63660
About us:
About us: Aoelec Electrical was established in 2003,with 50 office guys and 240 workers now.Our products are present in more than 30 different countries from Middle Ease to South American,from Europen to Australia,from Southeast Asia to North Africa.And our product have KEMA,TUV,SEMKO,CB and CE certificates.
About the supplier
Main products: Earth Leakage Circuit Breaker,Switch disconnector/Circuit breaker,Surge protector,Capacitor contactor,Safety Breaker,Other electrical and electronic products,Small breaker ( low-voltage apparatus)
