Metal shaper machine BC6063
- FOB goods (100)
- $650,000
- Ocean freight + handling (1.0 CBM)
- $820
- US duty (3.5%)
- $22,750
- Section 301 tariff (25.0%)
- $162,500
- Customs fees (MPF/HMF)
- $1,447
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- Service
- From $29 per supplier (Verify)
- You get
- Phone and video verification, a quote sheet and a written report
- Turnaround
- 3 business days
- Contact details
- Sent to you once your request is confirmed
If we can't reach the supplier within 3 business days, we refund the fee.
Metal shaper machine BC6063
- FOB goods (100)
- $650,000
- Ocean freight + handling (1.0 CBM)
- $820
- US duty (3.5%)
- $22,750
- Section 301 tariff (25.0%)
- $162,500
- Customs fees (MPF/HMF)
- $1,447
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- Service
- From $29 per supplier (Verify)
- You get
- Phone and video verification, a quote sheet and a written report
- Turnaround
- 3 business days
- Contact details
- Sent to you once your request is confirmed
If we can't reach the supplier within 3 business days, we refund the fee.
About this product
- Materials: Metal
- Size: 2000x1300xx150mm
- Color: White and Blue
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Anhui, China
About this product
- Materials: Metal
- Size: 2000x1300xx150mm
- Color: White and Blue
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Anhui, China
Product details
| Materials | Metal |
|---|---|
| Size | 2000x1300xx150mm |
| Color | White and Blue |
From the supplier
1. Shaper workbench can about rotational angle worktable moving structure with lateral and lifting.
2. To planing inclined plane, thereby expanding the scope of use.
3. Feed system of shaper with a cam mechanism, adjust the feed quantity. Change the amount of knife, very convenient.
4. Shaper in knife system overload safety device is installed, when due to careless handling or by external influence and cutting overload when, take the knife itself slipping, nondestructive parts which guarantees the machine to normal operation.
5. The sliding pillow and bed rails and with speed gear pair and the main rail sliding surface, lubrication oil pump has played for circulating lubrication.
6. Shaper with parking brake mechanism, so the speed of transformation. When starting machine tools and parking, the power supply can not be cut off.
Main Specification: Specification BC6063 Maximum planing length 630mm Maximum distance from the bottom of the working table 385mm lateral travel 630mm Vertical stroke 360mm Tool frame travel 120mm Sleeper reciprocating times (per minute) 14/20/28/40/56/80 Main motor power 3W The maximum size(width*thickness)of the handle 20×30mm The size of the T groove in the center of the worktable 18mm Angle of rotation ±60°(toolpost) Workbench size 630×400/660×400mm Shape size 2000×1300×x150mm Machine tool weight (about) 1750/1870KG Package dimensions 2000/1300/1650mm Machine Details:
