Non Resilient-Seated Gate Valves Rising Stem Type
TESTS
HYDRAULIC TEST ACC TO MMS SP-70
SEAT:1.1XPN.BODY:1.5 XPN OPERATINGtorque test.
DESSIGN&MANUFACTURESTANDARD
ANSI CLASS 125#/150#
\n \n
APPLICABLE STANDARDS
1.FLANGE DRILLEDACC. TO TOANSI B16.1 class125/150
2.FACE TO FACE DIMENSIONACC.TO TOANSI B16.1 class125/150
3.FLANGE RAISED FACE FLANGE
4.MAXIMUM WORKING PRESSURE 125/150 psi
5. MAXIMUM WORKING TEMPERATURE 130℃
\n \n
MATERIAL LIST
1.BODY : GREY CAST IRON/DUCTILE IRON
2.WEDGE: GREY CAST IRON/DUCTILE IRON
3.STEM: BRASS OR STAINLESS STEEL
4.YOKE NUT: CAST BRASS
5.CAP: GREY CAST IRON/DUCTILE IRON
6.WHEEL: GREY CAST IRON/DUCTILE IRON
Dimensions Unit:mm
DN
L
H
D0
D
k
1-1/2\"
6-1/2\"
11\"
7\"
5\"
3-7/8\"
2\"
7-1/64\"
11-1/4\"
7\"
6\"
4-3/4\"
2-1/2\"
7-1/2\"
13-1/2\"
7\"
7\"
5-1/2\"
3\"
8\"
15-3/8\"
8\"
7-1/2\"
6\"
4\"
9-1/64\"
17-4/5\"
10\"
9\"
7-1/2\"
5\"
10\"
21\"
10\"
10\"
8-1/2\"
6\"
10-1/2\"
23-7/10\"
12\"
11\"
9-1/2\"
8\"
11-1/2\"
32\"
14\"
13-1/2\"
11-3/4\"
10\"
13\"
36-4/5\"
16\"
16\"
14-1/4\"
12\"
14-1/64\"
42-5/8\"
18\"
19\"
17\"
