About this product
- Size: 53*29*32 cm
- Color: Black
- Exports to: Middle East, Southeast Asia, South Asia, Central Asia, EU, Other European Countries
About this product
- Size: 53*29*32 cm
- Color: Black
- Exports to: Middle East, Southeast Asia, South Asia, Central Asia, EU, Other European Countries
Product details
| Size | 53*29*32 cm |
|---|---|
| Color | Black |
From the supplier
NOTES:
ELECTRICAL:
1. VOLTAGE RATING : 125 VAC RMS
2. CURRENT RATING : 1.5 AMP
3. CONTACT RESISTANCE : 20 MILLIOHMS MAX
4. INSULATION RESISTANCE 100 MECOHMS MIN 。500 VDC
5. DIELECTRIC STRENCTH : 750 VAC RMS 60Hz,1MIN
6.C6 PERMANENT LINK : CONFORM TO ANSI/TIA/EIA-568 B.2- 1
ENMRONMENTAL
1.STORAGE : -40”TO +70°
2. OPERATION: -10”TO +60°
RJ45 JACKS COMPLY TO REQUIREMENTS OF IEC- 60603-7-5
MATES WITH MODUL AR PL _UG CONFORMING TO FCC PART 68
MECHANICAL :
1.SHIELD MATERIAL : BRASS C2680 T=0.25mm
2.HOUSING MATERIAL: PBT
3.CONTACT MATERIAL: PHOSPHOR BRONZE PL ATING GOLD
4.PANEL FRAME : Zn PLATING
5.IDC MATERIAL : PC,TERMINALPHOSPHOR BRONZE.TIN PLATING
6.RJ45 JACK UFE : 750 TIMES MIN
7.IDC UFE : 200 TMES MIN
8.WIRE : AWG 22~24
9.TIA Cat 6 Perm. Link Test: Worst pair NEXT margin≥3.0dB
Insertion Structure Retention: 50N, 60±5s
