Q8kh Automatic Strapping Machine
The supplier hasn’t listed a price. We can get their current prices and MOQ.
- Service
- From $29 per supplier (Verify)
- You get
- Phone and video verification, a quote sheet and a written report
- Turnaround
- 3 business days
- Contact details
- Sent to you once your request is confirmed
If we can't reach the supplier within 3 business days, we refund the fee.
Q8kh Automatic Strapping Machine
The supplier hasn’t listed a price. We can get their current prices and MOQ.
- Service
- From $29 per supplier (Verify)
- You get
- Phone and video verification, a quote sheet and a written report
- Turnaround
- 3 business days
- Contact details
- Sent to you once your request is confirmed
If we can't reach the supplier within 3 business days, we refund the fee.
About this product
- Materials: Iron
- Size: 1055*700*1400mm
- Color: Gray
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
About this product
- Materials: Iron
- Size: 1055*700*1400mm
- Color: Gray
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
Product details
| Materials | Iron |
|---|---|
| Size | 1055*700*1400mm |
| Color | Gray |
From the supplier
Q8S-M2 Built with durable spare parts and reliable electrical components. Germany Dunker Director current motor enables machine to start working as soon as power connected and No pre-heating and standby- time are required which will help save power consumption. Direct driving design guarantees a low maintenance. Reading tension percentage and heater temperature from the control panel. Faults happen statistics are stored for maintenance analysis.
Specification：
Strapping Speed
40 strap/min
Applicable Strapping band
PP strapping
Strapping width
7mm/9mm/10mm/12mm
Strapping Thickness
0.45-0.8mm
Sealing Method
Heat sealing
Strapping tension
2~88 Ibs / 1-40KG
Working Noise
78dBA
Strapping sizes
Max.: 800*500mm (24.4*19.7”)
Min.: 2.8*0.8”/ 70mm * 20mm
Arch size
24.4*19.7”/ 800*500mm
(other optional 24.4*19.7”/ 1000*500mm
24.4*19.7”/ 1250*500mm)
Layout dimension
49.4*27.6*55”/ 1255*700*1400mm
Power Supply
220V/110V 50Hz/60Hz
Power Consumption
0.5KW
Gross Weight
551 Ibs / 250KG
产品特性和优点:
High speed up to 40 straps/M
Auto Feeding
Direct motor driving,No belts.
Temperature and tension are displayed from screen
Germany Dunker DC 24V motor, Save power and safe.
Loop ejecting and re-feed function
Instant heating system, persistent temperature
Tension mode: Fixed tension and Fixed length
Switchable Manual and Auto operation
With counting function
One button to clear strap jam
Built for 24 hours continuous operation
Quick strap loading operation
No tooling required for maintenance
No maintenance for Gear box
Tension adjustment: Very easy from control panel
Easy strap loading and unloading
Front and rear pedal operation
