About this product
- Automatic grade: OtherNon Automation
- Customized: Non-CustomizedOtherCustomized
- Power source: OtherGasoline
- Walking mode: WheeledCrawlerOther
- Engine type: OtherDiesel Engine
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
- Made in: Changhzou, Jiangsu, China
About this product
- Automatic grade: OtherNon Automation
- Customized: Non-CustomizedOtherCustomized
- Power source: OtherGasoline
- Walking mode: WheeledCrawlerOther
- Engine type: OtherDiesel Engine
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China
- Made in: Changhzou, Jiangsu, China
Product details
| Automatic grade | OtherNon Automation |
|---|---|
| Customized | Non-CustomizedOtherCustomized |
| Power source | OtherGasoline |
| Walking mode | WheeledCrawlerOther |
| Engine type | OtherDiesel Engine |
Product details
| Automatic grade | OtherNon Automation |
|---|---|
| Customized | Non-CustomizedOtherCustomized |
| Power source | OtherGasoline |
| Walking mode | WheeledCrawlerOther |
| Engine type | OtherDiesel Engine |
From the supplier
Overall Dimension Total size
1
Length(with bucket on ground) Total length (with bucket on ground)*8020(mm)
2
Width(to outside of wheels) Total width (to outside of tire)2800(mm)
3
Bucket width Bucket width *2946(mm)
4
Height(To the top of the cab)*3450(mm)
5
Wheel base3100(mm)
6
Min. Minimum ground clearance450(mm)
Technical Specification Performance Parameters
1
Rated load5000(Kg)
2
Operating weight16500KG
3
Rated bucket capacity3.1(m3), optional 2.2-4.5 (m3)
4
Max. dump clearance Maximum unloading height3136(mm)
5
Dump reach unloading distance1171(mm)
6
Min. turning radius(wheel) minimum outer turning radius5970(mm)
Diesel engine engine
1
ModelWeiChai Weichai
WP10G220E343
WeiChai Weichai
WD10G220E23
2
Type formElectronic fuel injection electronic control
Direct injection. direct injection
3
Rated output Rated power162KW
162 (kW)
4
Rated speed2000
2000(r/min)
5
Max. Torque Maximum torque980(N.M)
900(N.M)@1400 r/min
Transmission System
1
Type form4-elements.single stage single stage four elements
2
Gear shift position2F, 1R front two rear gears
3
Speed (F/R)F：11.7/40.3 R：15.9
4
Max. Drawing force Maximum traction170kN
5
Size of tire model23.5-25-16PR
From the supplier
Overall Dimension Total size
1
Length(with bucket on ground) Total length (with bucket on ground)*8020(mm)
2
Width(to outside of wheels) Total width (to outside of tire)2800(mm)
3
Bucket width Bucket width *2946(mm)
4
Height(To the top of the cab)*3450(mm)
5
Wheel base3100(mm)
6
Min. Minimum ground clearance450(mm)
Technical Specification Performance Parameters
1
Rated load5000(Kg)
2
Operating weight16500KG
3
Rated bucket capacity3.1(m3), optional 2.2-4.5 (m3)
4
Max. dump clearance Maximum unloading height3136(mm)
5
Dump reach unloading distance1171(mm)
6
Min. turning radius(wheel) minimum outer turning radius5970(mm)
Diesel engine engine
1
ModelWeiChai Weichai
WP10G220E343
WeiChai Weichai
WD10G220E23
2
Type formElectronic fuel injection electronic control
Direct injection. direct injection
3
Rated output Rated power162KW
162 (kW)
4
Rated speed2000
2000(r/min)
5
Max. Torque Maximum torque980(N.M)
900(N.M)@1400 r/min
Transmission System
1
Type form4-elements.single stage single stage four elements
2
Gear shift position2F, 1R front two rear gears
3
Speed (F/R)F：11.7/40.3 R：15.9
4
Max. Drawing force Maximum traction170kN
5
Size of tire model23.5-25-16PR
