Solar Battery Charger Built-in lead acid battery LC-9813
LEOCH BATTERY(JIANGSU) CORP.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
Solar Battery Charger Built-in lead acid battery LC-9813
LEOCH BATTERY(JIANGSU) CORP.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: Fire-proof ABS material
- Size: 182*77*200
- Color: Black
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
About this product
- Materials: Fire-proof ABS material
- Size: 182*77*200
- Color: Black
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
Product details
| Materials | Fire-proof ABS material |
|---|---|
| Size | 182*77*200 |
| Color | Black |
Product details
| Materials | Fire-proof ABS material |
|---|---|
| Size | 182*77*200 |
| Color | Black |
From the supplier
Solar Battery Charger Built-in lead acid battery LC-9813 Features:
It is a portable multi-function outdoor mobile power system，Built-in lead acid battery with low internal resistance and high discharge rate, which is more safe than lithium battery; 12V 5.0L gasoline vehicle，Built-in smart charging control circuit, so that the battery will not shorten the life due to overcharging, the charging method is diversified, the system can be charged by using an external adapter supply and a solar panel。2 USB charging outlets can apply to charging for portable mobile production.
The battery power state by displaying different colors, the charging indicator shows the charging status, and the DC output indicator shows the load output status;There are 3 sets of 12V DC output interfaces, which can supply power to 12V energy-saving lamps and other portable devices. The built-in overcurrent protection circuit, when the output load exceeds the rated value, in order to avoid damage to the product, the system will be power off in time, when the load is reduced to the rated value , Resume output automatically.
Solar Battery Charger Built-in lead acid battery LC-9813 Specifications:
PART NO.LC-9813ⅠConventional electricalSolar control panel1System voltage12V DC2Solar input power90WMax3Solar charger input current18V5A Max
4Built-in battery capacity12V18AH with UL certification
5USB output two setsUSB1 5V±0.25VCC @2.1AUSB2 5V±0.25V6Battery indicator (red and green lights)Green light12V≤BATTOrange (red and green light simultaneously)11V≤BATT≤12VRed light onBATT≤11V7Load (discharge) status displayNormally lit means normal output, flashing output means short circuit or overcurrent protection
8Solar charging instructionsThe green LED flashes when the solar panel is connected to charge the built-in lead-acid battery
9Reverse protectionWhen the polarity of the solar cell is reversedYES
10CH5 output socketPeak current 900AStart function
General characteristics
1Discharge temperature range-20-50℃
2Charging temperature range0-40℃
3Operating humidity range10%-90%
4Storage humidity range5%-95%
5Size182*77*200 mm
6Solar battery input socket1PCS 5.5*2.5mm
7DC output socket3PCS 5.5*2.1mm
8Packingcustomize
9spare part12V1W LED 2PCS
10spare partOne-terminal CH5 plug, another terminal clamp UL1015 10AWG with reverse connection and fuse high current start line1PCS
11spare partOne head with 2.5mmDC head + 8 meters 2468 red and black 22 # + screw lamp head with switch2PCS
12spare part30W folding solar panel1PCS
13spare partUL2464 20# L=5m Solar Wire with 2.5 * 5.5DC Head1PCS
14spare partAC charging adapter 18V1000mA 1PCSAC plug model is optinal according to order
15Net Weight6KG
From the supplier
Solar Battery Charger Built-in lead acid battery LC-9813 Features:
It is a portable multi-function outdoor mobile power system，Built-in lead acid battery with low internal resistance and high discharge rate, which is more safe than lithium battery; 12V 5.0L gasoline vehicle，Built-in smart charging control circuit, so that the battery will not shorten the life due to overcharging, the charging method is diversified, the system can be charged by using an external adapter supply and a solar panel。2 USB charging outlets can apply to charging for portable mobile production.
The battery power state by displaying different colors, the charging indicator shows the charging status, and the DC output indicator shows the load output status;There are 3 sets of 12V DC output interfaces, which can supply power to 12V energy-saving lamps and other portable devices. The built-in overcurrent protection circuit, when the output load exceeds the rated value, in order to avoid damage to the product, the system will be power off in time, when the load is reduced to the rated value , Resume output automatically.
Solar Battery Charger Built-in lead acid battery LC-9813 Specifications:
PART NO.LC-9813ⅠConventional electricalSolar control panel1System voltage12V DC2Solar input power90WMax3Solar charger input current18V5A Max
4Built-in battery capacity12V18AH with UL certification
5USB output two setsUSB1 5V±0.25VCC @2.1AUSB2 5V±0.25V6Battery indicator (red and green lights)Green light12V≤BATTOrange (red and green light simultaneously)11V≤BATT≤12VRed light onBATT≤11V7Load (discharge) status displayNormally lit means normal output, flashing output means short circuit or overcurrent protection
8Solar charging instructionsThe green LED flashes when the solar panel is connected to charge the built-in lead-acid battery
9Reverse protectionWhen the polarity of the solar cell is reversedYES
10CH5 output socketPeak current 900AStart function
General characteristics
1Discharge temperature range-20-50℃
2Charging temperature range0-40℃
3Operating humidity range10%-90%
4Storage humidity range5%-95%
5Size182*77*200 mm
6Solar battery input socket1PCS 5.5*2.5mm
7DC output socket3PCS 5.5*2.1mm
8Packingcustomize
9spare part12V1W LED 2PCS
10spare partOne-terminal CH5 plug, another terminal clamp UL1015 10AWG with reverse connection and fuse high current start line1PCS
11spare partOne head with 2.5mmDC head + 8 meters 2468 red and black 22 # + screw lamp head with switch2PCS
12spare part30W folding solar panel1PCS
13spare partUL2464 20# L=5m Solar Wire with 2.5 * 5.5DC Head1PCS
14spare partAC charging adapter 18V1000mA 1PCSAC plug model is optinal according to order
15Net Weight6KG
