About this product
- Materials: metal
- Size: 2560×2430×1920mm
- Color: customize
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Anhui, China
About this product
- Materials: metal
- Size: 2560×2430×1920mm
- Color: customize
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Anhui, China
Product details
| Materials | metal |
|---|---|
| Size | 2560×2430×1920mm |
| Color | customize |
From the supplier
Surface grinding machine Features:
1. The machine is reasonable in structure, good rigidity, beautiful apperance, convenient operation.
2. Using precision plastic guide surface an precision scraping, grinding imported hydraulic transmission, drive by synchronous;
3. The main mechanical valve is a special valve grinder, is divided into two parts, the mechanical commutation vontrol, throttle control. Throttle control part and unloading function, can realize the station start and stop.
4. Grinding can be all kinds of plane and complex shaped surface, suitable for motor without grinding feed, according to user needs with a permanent magnet sucker or electromagnetic sucker.
SpecificationMY1230Max workpiece to be ground700x320mmMax travel of table640x370mmTable max cutting area760x370mmT-slot (number width)1x14mmDistance from table to spindle center540mmWheel size (dia width bore)335x40x127mmSpindle speed1440r/mTable longitudinal (left and right) speed5-25/minTable horizontal Continuous (variable speed)150mm/min(before and after)Intermittent (stepless)0-5the amount of feedThe handlewheel rotates4mm
Hand wheel each grid0.02mmVertical (up and down)The handlewheel rotates2mmfeed wheel feedHand wheel each grid0.01mmSpindle motor4mmCooling motor40kwHydraulic motor1.5kwWorking pressure3mpaOil tank capacity80LMax capacity18L/minThe mechanical surface of the base of parallelism300/0.004mmSurface roughnessRa0.32umN.W.2.1TG.W.2.35TMachine size25600x2430x1920mm
