Tangent Suspension Clamp for ADSS Fiber Optical Cables
ADSS Tangential Suspension Clamp
ADSS Tangential Suspension Clamp is connecting hardware used to suspend ADSS optical cable on power transmission line poles and towers. The clamp reduces static stress on the optical cable at suspension points, improves vibration resistance, and suppresses dynamic stress from wind vibration. It ensures optical cable bending does not exceed allowable values, preventing bending stress so optical fiber experiences no additional loss.
Tangent suspension clamp for ADSS fiber optical cables is the connection fittings for ADSS cable in transmission line for pole and tower. It can reduce the static stress at the suspension point of the cable, and raise the cable anti vibration ability, inhibition of wind vibration of dynamic stress; It can also keep the cable bending and it does not exceed the allowable numerical and the cable will not generate bending stress, so the cable optical fiber does not produce additional loss.
For use on:
Span less than 100m, no armor rods
Spans Below 100 Meters, No Guard Wire
Catalog Number
Product Model
Diameter Range(mm)
Cable Diameter Range
ACL 1110 002
10.0-11.1
ACL 1220 002
11.2-12.2
ACL 1330 002
12.3-13.3
ACL 1440 002
13.4-14.4
ACL 1550 002
14.5-15.5
ACL 1660 002
15.6-16.6
ACL 1770 002
16.7-17.7
ACL 1880 002
17.8-18.8
ACL 1990 002
18.9-19.9
For use on:
100-400 meters, 1 layer
Suitable for 100-400m span, single-layer cable guard
Catalog Number
Product Model
Diameter Range(mm)
Cable Diameter Range
Average Weight(kg)
Weight
Length (mm)
Length
ACL 1050 030
9.5-10.5
0.83
680
ACL 1160 030
10.6-11.6
0.94
730
ACL 1270 030
11.7-12.7
1.06
850
ACL 1380 030
12.8-13.8
1.18
880
ACL 1490 030
13.9-14.9
1.30
880
