Underground duct direct buried outdoor armored fiber optic cable
ZHUHAI SURELINK COMMUNICATION CABLE CO.,LTD.
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
Underground duct direct buried outdoor armored fiber optic cable
ZHUHAI SURELINK COMMUNICATION CABLE CO.,LTD.The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Size: 10cm
- Color: black
- Operation temperature: -
- Conductor material: Other
- Insulation material: PEOther
- Application: UndergroundTelecommunication
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries
About this product
- Size: 10cm
- Color: black
- Operation temperature: -
- Conductor material: Other
- Insulation material: PEOther
- Application: UndergroundTelecommunication
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries
Product details
| Size | 10cm |
|---|---|
| Color | black |
| Operation temperature | - |
| Conductor material | Other |
| Insulation material | PEOther |
| Application | UndergroundTelecommunication |
| Voltage type | LowVoltage |
| Technique | Other |
Product details
| Size | 10cm |
|---|---|
| Color | black |
| Operation temperature | - |
| Conductor material | Other |
| Insulation material | PEOther |
| Application | UndergroundTelecommunication |
| Voltage type | LowVoltage |
| Technique | Other |
From the supplier
SURELINK Outdoor Duct Singlemode Steel Tape Armoured Fibra Optica Cable GYTS GYTA 24 48 96 144 288 Core Fiber Optical Cable
Product Specifications
1. Product Structure
2. Technical Specification
Product Construction:
1. Fiber:2-288 fiber Multi-loose tube gel-filled
2. Central Strength Member: Fiberglass reinforced Platic (FRP) or steel wire.
3. Armor:Aluminum Tape Armor
4. Outer Jacket:Black UV Polyethylene(PE)
Application:
Interbuilding voice or data communication backbone.
Installed in duct, underground conduit .
3. Optical Characteristics:
Fiber Type G.652 G.655 50/125^m 62.5/125^m Attenuation(+20X) 850 nm <3.0 dB/km <3.3 dB/km 1300 nm <1.0 dB/km <1.0 dB/km 1310 nm <0.36 dB/km <0.40 dB/km 1550 nm <0.22 dB/km <0.23 dB/km Bandwidth 850 nm >500 MHz-km >200 Mhz-km 1300 nm >500 MHz-km >500 Mhz-km Numerical Aperture 0.200±0.015 NA 0.275±0.015 NA Cable Cut-off Wavelength cc <1260 nm <1450 nm
4. Structure and Technical Specifications Fiber
Count Nominal
Diameter
(mm) Nominal
Weight
(kg/km) Max Fiber
Per Tube
Max No.
of (Tubes+
fillers)
Allowable TensileLoad(N) Allowable Crush
Resistance(N/100mm) Short Term Long Term Short Term Long Term 2~36 10.3 109 6 6 1500 600 1000 300 38~72 11.5 145 12 6 1500 600 1000 300 74~96 13.5 175 12 8 1500 600 1000 300
ADSS cable fttx fiber optic cable ftth fiber optic cable
Fiber Optic Terminal Box Fiber Optic Drop wire clamp Fast Connector
Email:sales@zhsurelink.com
Wechat: surelink2008
WhatsApp: +86 13926923676
https://www.zhsurelink.com
From the supplier
SURELINK Outdoor Duct Singlemode Steel Tape Armoured Fibra Optica Cable GYTS GYTA 24 48 96 144 288 Core Fiber Optical Cable
Product Specifications
1. Product Structure
2. Technical Specification
Product Construction:
1. Fiber:2-288 fiber Multi-loose tube gel-filled
2. Central Strength Member: Fiberglass reinforced Platic (FRP) or steel wire.
3. Armor:Aluminum Tape Armor
4. Outer Jacket:Black UV Polyethylene(PE)
Application:
Interbuilding voice or data communication backbone.
Installed in duct, underground conduit .
3. Optical Characteristics:
Fiber Type G.652 G.655 50/125^m 62.5/125^m Attenuation(+20X) 850 nm <3.0 dB/km <3.3 dB/km 1300 nm <1.0 dB/km <1.0 dB/km 1310 nm <0.36 dB/km <0.40 dB/km 1550 nm <0.22 dB/km <0.23 dB/km Bandwidth 850 nm >500 MHz-km >200 Mhz-km 1300 nm >500 MHz-km >500 Mhz-km Numerical Aperture 0.200±0.015 NA 0.275±0.015 NA Cable Cut-off Wavelength cc <1260 nm <1450 nm
4. Structure and Technical Specifications Fiber
Count Nominal
Diameter
(mm) Nominal
Weight
(kg/km) Max Fiber
Per Tube
Max No.
of (Tubes+
fillers)
Allowable TensileLoad(N) Allowable Crush
Resistance(N/100mm) Short Term Long Term Short Term Long Term 2~36 10.3 109 6 6 1500 600 1000 300 38~72 11.5 145 12 6 1500 600 1000 300 74~96 13.5 175 12 8 1500 600 1000 300
ADSS cable fttx fiber optic cable ftth fiber optic cable
Fiber Optic Terminal Box Fiber Optic Drop wire clamp Fast Connector
Email:sales@zhsurelink.com
Wechat: surelink2008
WhatsApp: +86 13926923676
https://www.zhsurelink.com
