YANSHUO YG825E Digital Fabric Water Permeability Tester One-key Drainage | Built-in Water Tank
Xi'an Yanshuo Instrument Equipment Co., Ltd.1/10 fairsManufacturer
Price on request
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
YANSHUO YG825E Digital Fabric Water Permeability Tester One-key Drainage | Built-in Water Tank
Xi'an Yanshuo Instrument Equipment Co., Ltd.1/10 fairsManufacturer
Price on request
The supplier hasn’t listed a price. We can get their current prices and MOQ.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Size: 550×400×800mm
- Color: gray
- Structure: Other
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
About this product
- Size: 550×400×800mm
- Color: gray
- Structure: Other
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
Product details
| Size | 550×400×800mm |
|---|---|
| Color | gray |
| Structure | Other |
Product details
| Size | 550×400×800mm |
|---|---|
| Color | gray |
| Structure | Other |
From the supplier
Applicable Standards
GB/T 4744-2013, FZ/T 01004-91, ISO 811, AATCC 127, JIS L 1092, YY/T 0506-2023, etc.
Instrument Features
- 7-inch color LCD touch screen with Chinese menu, simple and intuitive operation.
- One-key drainage function for more convenient testing.
- Built-in 5 test modes to fully meet various test standards.
- Built-in multi-unit selection, no need to convert test results.
- Adopts high-precision pressure sensor, ensuring accurate, stable test results with good repeatability.
- Equipped with a built-in water tank and water shortage protection function.
- Measuring Range & Accuracy
- Specimen clamping area: 100 cm²
- Water pressure rising rate: 0–30000 Pa/min
- Display resolution: ≤10 Pa
- Test units: Pa, kPa, mmH₂O, cmH₂O, mbar
- Working modes: 5 types
- Display mode: Color LCD touch screen with Chinese menu
- Water tank capacity: 3000 ml
- Power supply: AC 220V ±10%, 50Hz
- Power: 120W
- Dimensions: 550×400×800 mm
- Weight: 75 kg
From the supplier
Applicable Standards
GB/T 4744-2013, FZ/T 01004-91, ISO 811, AATCC 127, JIS L 1092, YY/T 0506-2023, etc.
Instrument Features
- 7-inch color LCD touch screen with Chinese menu, simple and intuitive operation.
- One-key drainage function for more convenient testing.
- Built-in 5 test modes to fully meet various test standards.
- Built-in multi-unit selection, no need to convert test results.
- Adopts high-precision pressure sensor, ensuring accurate, stable test results with good repeatability.
- Equipped with a built-in water tank and water shortage protection function.
- Measuring Range & Accuracy
- Specimen clamping area: 100 cm²
- Water pressure rising rate: 0–30000 Pa/min
- Display resolution: ≤10 Pa
- Test units: Pa, kPa, mmH₂O, cmH₂O, mbar
- Working modes: 5 types
- Display mode: Color LCD touch screen with Chinese menu
- Water tank capacity: 3000 ml
- Power supply: AC 220V ±10%, 50Hz
- Power: 120W
- Dimensions: 550×400×800 mm
- Weight: 75 kg
