Product Description Cost-effective High-low Noise 100kva 125kva 200kva Weichai Engine Diesel Generator Set

Overview

Application scenario

● 100kVA: Suitable for small enterprises, shops, small data centers, etc., as a backup power supply to ensure basic power needs, such as lighting, small office equipment and other power supply.

● 125kVA: can be used in medium-sized shops, small factories, construction sites, etc., can meet some slightly higher power equipment electricity, such as small production equipment, construction machinery, etc.

● 200kVA: often used in large commercial places, medium-sized factories, hospitals, schools, etc., can guarantee key equipment and large-scale power systems, such as medical equipment, teaching buildings, etc.

Land Based Genset-JW-WP66 Gen-set specifications Model JW-WP66 Standby Rating kVAkWe 68.5/55 Prime Rating kVAkWe 62.5/50 Voltage V 400/230 Frequency Hz 50 Power Factor 0.8(lagging) No.of Phases 3 Fuel consumption@25%/50%/75%(Lh) 4.34/7.12/9.46 Fuel consumption@100%/110%(Lh) 13/14.13 Sound@1m(dB · (A)) Open≤105 dB(A);Silence≤85 dB(A) Ambient temp(℃) -10~45 Gen-set regulation class ISO8528-5 G2 Steady-state voltage deviation ≤±2.5%;≤±5% Transient voltage deviation
(100%sudden power decrease/increase) +25%;-20% Steady-state frequency band ≤1.5% Transient frequency deviation from rated frequency
(100%sudden power decrease/increase) +12%;-10% Standard Features ◆ Electronic governor ◆DC24 Electric starter ◆JW-WHC6120NC ◆Closed water-cooled ◆ IP23 ◆H type insulation ◆Air filter ◆Muffler ◆Circuit Breaker ◆Startingbatteries ◆with connective wires ◆ Radiator ◆Oil Drain Valve ◆Forklift Groove ◆Shock Absorber ◆Color Weichai blue(B,F)/beige canopy and black chassis(L) ◆ Packagng packing case(B,F) Options OVoltage380V/415V OVoltage 440V/480V ◇Extemal fue tank
(1000L/1500L) ◇Single Voltage 220V/230V OAutomatic Transfer Switch ◇Altermator heater ◇Engine Heater(water) ◇PMG/AREP

We have cooperation with worldwide famous brands. For more specification,please contact us. FAQ 1.Q: What is your MOQ of this item?
A:1 Sets. Q: What is the lead time?
A:7 working days after received the 30%T/T deposit.
3.Q: Is it all right to make customer's own brand name?
A:We can be your OEM manufacture with your authorization of brand.
4.Q: Where is your Loading Port?
A:Shanghai or others.
5.Q: What are your payment terms?
A:30% TT as deposit,70% TT before Shipment.
6.Q: What is your company's available production capacity?
A:100 Sets per month.
7.Q:What's the warranty time of diesel generators?
A:12 months or 1000 working hours, whichever comes first.
