About this product
- Materials: Steel
- Size: 5160*2185*1400
- Color: Grey
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Others
- Made in: Jiangsu, China
About this product
- Materials: Steel
- Size: 5160*2185*1400
- Color: Grey
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Others
- Made in: Jiangsu, China
Product details
| Materials | Steel |
|---|---|
| Size | 5160*2185*1400 |
| Color | Grey |
From the supplier
〇Intelligent control system with large touch screen display. Available in various different languages display menu, easy to operate.
〇 The sensors can detect the size of towels and adjust the width accordingly. The lateral fold is done with folding plate.
〇The coder installed on the shaft measures the length of towel and selects folding method accordingly. The first cross fold is done via positive-reverse run and air blow.
〇The innovative machine design will adjust its template to suit the thickness and weight of towel to ensure good quality folding and execute the second cross fold.
〇The second cross fold is done by special positive-reverse run and air blow, and an adjustable transport platform is added to ensure good quality.
〇Discharge precisely positioned. Automatically and fast.
〇Intelligent control adopted, combining with international technology of computer and communication, the controlling system is designed for actual requirements of towel folder folding, which posseses individual built-in software and comprehensive detecting function.
〇Programs can be made as desired. Manual and automatic modes are available. Full automation and easy operation can simply perform folding for many kinds of towel.
〇An autostretch device is installed for discharge, which can stretch and retract so as to transfer the piles of towels to the next conveying belt smoothly.
Description
ZDMJ 1920-1200
Externally connected compressed air pressure
MPa
0.5-0.7
Compressed air connection dia
mm
∮12
Air consumption
L/min
200
Power supply
V/P/Hz
380/3/50
Frequency
Hz
50
Rated motor power
kW
1.8
Power consumption
kW.h/h
1.8
Controller voltage
V.DC
24
Cycle time
second
3-7
Capacity
pcs/h
800-1200
Max.size of towel before folding
mm
1100×1820
Max.size of towel after folding
mm
450×600
Way of lateral folding(width adjusted from 140-380mm)
by pass
cross
1/3 folds
Cross fold A＆B
by pass
cross in＆out
folds
s-type1/3 folds
2cross folds
Dimension (L/W/H)
mm
3818/1320/1305
Total dimension with stacker (L/W/H)
mm
5160/2185/1400
Weight
kg
1380
