About this product
- Materials: carbon steel and S.S
- Size: 4000X2000X2300
- Color: white and grey
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, Other European Countries, Others
- Made in: Jiangsu, China
About this product
- Materials: carbon steel and S.S
- Size: 4000X2000X2300
- Color: white and grey
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, Other European Countries, Others
- Made in: Jiangsu, China
Product details
| Materials | carbon steel and S.S |
|---|---|
| Size | 4000X2000X2300 |
| Color | white and grey |
From the supplier
JR series full-automatic blowing machine can blow hollow plastic vessels of various calibers. The product quality is stable; the structure is reasonable; it has small volume, less energy consumption, convenient operation and maintenance.
All the mechanical parts of the JR series full-automatic blowing machine are treated with high technology, processed elaborately and assembled delicately to meet the technical requirements of various aspects. The moving parts adopt boundary lubricating bearing and straight line guide rail pair (Japanese slider) connection; mechanical collision adopt buffer (Japanese), thus the mechanical noise is low, the fault rate is low and the service life is long. The unique blowing machine design make it has a quite high yield rate. The operation of JR series machine is fully controlled by computer; the action is accurate and reliable. The humane operation and machine running monitoring are realized through human-machine interface.
Pneumatic part
Valve
SMC
Cylinder
Electric part
PLC
SIEMENS
Operating system
SIEMENS
Relay
OMRON
Servo motor National
SCHNEIDER
Note
All of the electrical components adopts CE、UL、CCC approved international advanced high-tech product.
Main parameter
Model
JR60SC
Productivity
Depend on bottle design
6000-7500BPH
Product type
Body diameter
≤90mm
Height
≤325mm
Neck diameter
28mm-30mm
Mold
Cavity
6cavities
Mold thick
240mm
Main machine power
Electrical source power
380v 3Phase /220v 3Phase 50/60HZ
Rated Power
143kw
Really use power
Air source
HP air compressor
6.4m3/min
Air dryer
8.0m3/min
Cooling water
Cooling water
5HP
Size
L*W*H
5670*2180*2300mm
Weight
9000kg
Resin available
/
PET
