chemical process pump
The supplier hasn’t listed a price. We can get their current prices and MOQ.
- Service
- From $29 per supplier (Verify)
- You get
- Phone and video verification, a quote sheet and a written report
- Turnaround
- 3 business days
- Contact details
- Sent to you once your request is confirmed
If we can't reach the supplier within 3 business days, we refund the fee.
chemical process pump
The supplier hasn’t listed a price. We can get their current prices and MOQ.
- Service
- From $29 per supplier (Verify)
- You get
- Phone and video verification, a quote sheet and a written report
- Turnaround
- 3 business days
- Contact details
- Sent to you once your request is confirmed
If we can't reach the supplier within 3 business days, we refund the fee.
About this product
- Materials: Stainless Steel
- Size: 详情咨询
- Color: Stainless steel color
- Application: Other
- Fuel: Other
- Standard: Standard
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
About this product
- Materials: Stainless Steel
- Size: 详情咨询
- Color: Stainless steel color
- Application: Other
- Fuel: Other
- Standard: Standard
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
Product details
| Materials | Stainless Steel |
|---|---|
| Size | 详情咨询 |
| Color | Stainless steel color |
| Application | Other |
| Fuel | Other |
| Standard | Standard |
| Structure | Single-Stage Pump |
| Usage | Other |
| Theory | Centrifugal Pump |
From the supplier
ISO2858/5199,DIN24256.,EN 25199/22858 standard
Fields of Applications
- Chemical and Pertrochemical industry
- Oil refining plants
- Paper making industry
- Sugar indystry
- Waste water treatment
- Pharmaceutical
- Food industry
Performance Coverage
Inlet Diameter: 50~350mm
Outlet Diameter: 32~300mm
Pump speed: 50Hz--2900/1450/980/740/580 rpm
60Hz--3500/1750/1180/890/710 rpm
Flow rate: 6~1950m3/h(50Hz)
Pump head: 5~160m(50Hz)
Temperature: T up to150°C
Working pressure: up to 24Bar(20°C)
Materials
Casing: Stainless steel 304/Stainless steel316,Duplex stainless steel
Impeller: Stainless steel 304/Stainless steel316,Duplex stainless steel
Shaft: Stainless steel 304/Stainless steel316,Duplex stainless steel
Wear ring: Stainless steel 304/Stainless steel316,Duplex stainless steel
Bearing: Original Japanese Brand NTN as standard
-Standard: Single Mechanical seal M7N -Carbon/Silicon carbide /Ptfe
-Option--Dual Mechanical seal M74D and Cartridge mechanical seal
About the supplier
Main products: Other Pumps
- ✓Exhibited at 10 of the last 10 Canton Fairs
- ✓Manufacturer
- ✓Founded 2010
- ✓Canton Fair Premium Supplier
- ✓National high-tech enterprise
- Exhibited at 10 of the last 10 Canton Fairs
- Manufacturer
- Founded 2010
- Canton Fair Premium Supplier
