From the supplier
I. Description:
The friction welding machine use friction as heat source, make the two pieces of friction and produce heat by the mechanical movement and the application of axial pressure quickly, and make the friction contact surface heated to plastic state, quickly stop and apply a larger axial pressure, and then keep appropriate pressure for some time. The friction machine is the profession welding machine, make use of heat to weld the same and dissimilar metals together .
The Friction welding machine is high quality, high efficiency, energy saving, low consumption, no pollution and other significant features. Welding quality is stable and reliable, high precision welding, easy for easy, easy to achieve automatic control, is an environmentally friendly, energy-saving products.
Friction welding machine is widely used in aerospace, automobile, machinery manufacturing, tool cutting tools, power fittings, geological exploration, oil drilling and other high-tech and traditional industries, mainly for shaft, pipe and other parts of the welding, such as internal combustion engine valve, valve stem, supercharger, universal joint ball cage, drive shaft, pump shaft 45 # steel + stainless steel, ball pin, drill, tap, cutter, cutter, copper and aluminum joints, Building ribs and so on.
C4 friction welding machine can be use for weld Φ8-Φ18 copper and aluminum.
II. Main Technical Parameters:
1
Max. forging force
KN
100
2
Speed of Spindle
r/min
2200
3
The diameter of work piece
mm
10-25
4
The Max. Stroke of worktable
mm
260
5
The length of Rotating clamp
mm
50-200
6
Moving clamp type
mm
Special clamp
7
The length of Moving clamp
mm
50-500
8
The Max. rotating clamp force
KN
40
9
The Max.moving clamp force
KN
40
10
The level of pressure
Level two (friction+forging)
11
Time of friction
0—100S(adjustable)
12
Forging keeping pressure time
0—100S(adjustable)
13
Friction forging force
1.5—100KN(adjustable)
14
Working speed
2—20mm/s(adjustable)
15
Quick feeding speed
m/min
15
16
Main motor power
15KW-2
17
Hydraulic motor power
5.5KW
18
Productivity
pc/hour
120—400
19
Floor space
mm
2600X2500X1250
20
Net weight
kg
3500
III. Main Configuration
3.1. Main motor LiChao, Local famous brand
3.2. Guide rail Shangyin, Taiwan
3.3. PLC Mitsubishi, Japan
3.4. Touch screen HWIN
3.5. Low voltage apparatus Schneider
3.6. Bearing NSK, Japan
