About this product
- Materials: HMWPE insulated + steel armourd + copper conductor
- Size: 20mm*20mm
- Color: black，red，white、accept customized
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Henan, China
About this product
- Materials: HMWPE insulated + steel armourd + copper conductor
- Size: 20mm*20mm
- Color: black，red，white、accept customized
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Henan, China
Product details
| Materials | HMWPE insulated + steel armourd + copper conductor |
|---|---|
| Size | 20mm*20mm |
| Color | black，red，white、accept customized |
Product details
| Materials | HMWPE insulated + steel armourd + copper conductor |
|---|---|
| Size | 20mm*20mm |
| Color | black，red，white、accept customized |
From the supplier
1.Application
The cathodic protection cable mainly used for impressed current cathodic protection system It has excellent electrical properties ,mechanical behavior, heat aging property ,resistance to environment stress and chemical corrosion resistance ability ,very low water absorption and simple structure ,easy to use and not retain by laying fall etc.
2. Construction:
1.Type :CPVV,CPY,CPFY,CPFY33
2.Core number :1 core
3.Conductor cross section:10,16,25,35,50,70
3.Characteristic:
1.Rate voltage:DC600V
2.Long-term permissible working temperature of cable conductor :
PVC insulated cable:70℃
HMWPE insulated cable:90℃
PVDF/KYNAR insulated cable:135℃
3.The layout temperature of cable shall not be lower than -20℃
4.The bending radius :20D,(D is outer diameter cable )
4.Standard:
The products is equivalent to the national standard GB 16702 and the national petroleum company of Saudi Arabia 17-SAMSS-017 (impressed current cathodic protection cable procurement norms)of our corporate standard to organize production. The company also may require the user or by other standard ,designing and manufacturing some special functions of cathodic protection cable .
From the supplier
1.Application
The cathodic protection cable mainly used for impressed current cathodic protection system It has excellent electrical properties ,mechanical behavior, heat aging property ,resistance to environment stress and chemical corrosion resistance ability ,very low water absorption and simple structure ,easy to use and not retain by laying fall etc.
2. Construction:
1.Type :CPVV,CPY,CPFY,CPFY33
2.Core number :1 core
3.Conductor cross section:10,16,25,35,50,70
3.Characteristic:
1.Rate voltage:DC600V
2.Long-term permissible working temperature of cable conductor :
PVC insulated cable:70℃
HMWPE insulated cable:90℃
PVDF/KYNAR insulated cable:135℃
3.The layout temperature of cable shall not be lower than -20℃
4.The bending radius :20D,(D is outer diameter cable )
4.Standard:
The products is equivalent to the national standard GB 16702 and the national petroleum company of Saudi Arabia 17-SAMSS-017 (impressed current cathodic protection cable procurement norms)of our corporate standard to organize production. The company also may require the user or by other standard ,designing and manufacturing some special functions of cathodic protection cable .
