From the supplier
Hot blast stoves are thermal energy conversion equipment that uses fuels (blast furnace gas, coke oven gas, converter gas, mixed gas, producer gas, calcium carbide furnace gas, natural gas, petroleum liquefied gas, diesel oil, heavy oil, pulverized coal and garbage, etc.) to burn in the furnace to release chemical energy, heating low-temperature air to high-temperature air at a certain temperature.hot blast stoveOther heat energy (such as electricity, waste heat) can also be used to heat the air.
Performance characteristics:
1. It is widely applicable to fuel varieties. It can be used to make fuels such as blast furnace gas, coke oven gas, converter gas, mixed gas, producer gas, natural gas, petroleum liquefied gas, chemical waste gas, heavy oil, diesel, pulverized coal and other fuels.hot blast stove。
2. The output hot air temperature is controlled, and the temperature difference is within ±5℃.
3. Aiming at the temperature of the control point, the supply of fuel and air is automatically adjusted, making it easy to use.
4. Non-standardized design is highly targeted and can better meet user requirements.
5. The output hot air temperature control range is wide, which can be applied to the drying needs of different industries.
6. It can continuously provide constant temperature, constant pressure and purified hot air.
7. Fully automatic operation, using imported electrical components, high operation reliability and accuracy, and can be networked with industrial configuration control.
Technical performance table:
item of model number
heating capacity
Kcal/h
design gas volume
Nm³/h
amount of gas
Nm³/h
Power regulation range
KW
thermal efficiency
%
WRF50T-Z
50X10⁴
60
20-70
200-700
>95
WRF100T-Z
100X10⁴
120
40-140
400-1300
>95
WRF200T-Z
200X10⁴
240
60-300
700-2600
>95
WRF300T-Z
300X10⁴
360
100-400
1100-4000
>95
WRF400T-Z
400X10⁴
480
150-550
1400-5200
>95
WRF500T-Z
500X10⁴
600
200-650
1800-6500
>95
WRF600T-Z
600X10⁴
720
250-800
2000-8000
>95
WRF800T-Z
800X10⁴
960
300-1100
2800-10000
>95
WRF1000T-Z
1000X10⁴
1200
400-1400
3500-13000
>95
WRF1200T-Z
1200X10⁴
1440
450-1600
4200-16000
>95
WRF1500T-Z
1500X10⁴
1800
500-2000
5500-20000
>95
WRF2000T-Z
2000X10⁴
2400
750-2700
7000-25000
>95
WRF2500T-Z
2500X10⁴
3000
900-3300
9000-32000
>95
WRF3000T-Z
3000X10⁴
3600
1100-4000
11000-40000
>95
WRF3500T-Z
3500X10⁴
4200
1300-4800
13000-45000
>95
WRF4000T-Z
4000X10⁴
4800
1500-5500
14000-50000
>95
WRF4500T-Z
4500X10⁴
5400
1700-6000
16000-60000
>95
WRF5000T-Z
5000X10⁴
6000
1800-6600
1 8000-65000
>95
Note: ① Take Qdw=8500Kcal/Nm³ natural gas, horizontal direct-fired hot blast stove as an example② Product specifications can also be designed according to user requirements
Model expression meaning:
