LFM32 Series Differential Pressure Gauge meter for positive and negative pressure for clean room
ZHEJIANG LEFOO CONTROLS CO., LTD.
See what’s includedHide breakdown
- FOB goods (100)
- $8,056
- Ocean freight + handling (2.0 CBM, volume guessed from price)
- $942
- US duty (3.5%)
- $282
- Section 301 tariff (25.0%)
- $2,014
- Customs fees (MPF/HMF)
- $43
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- FOB goods (100)
- $8,056
- Ocean freight + handling (2.0 CBM, volume guessed from price)
- $942
- US duty (3.5%)
- $282
- Section 301 tariff (25.0%)
- $2,014
- Customs fees (MPF/HMF)
- $43
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
LFM32 Series Differential Pressure Gauge meter for positive and negative pressure for clean room
ZHEJIANG LEFOO CONTROLS CO., LTD.See what’s includedHide breakdown
- FOB goods (100)
- $8,056
- Ocean freight + handling (2.0 CBM, volume guessed from price)
- $942
- US duty (3.5%)
- $282
- Section 301 tariff (25.0%)
- $2,014
- Customs fees (MPF/HMF)
- $43
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- FOB goods (100)
- $8,056
- Ocean freight + handling (2.0 CBM, volume guessed from price)
- $942
- US duty (3.5%)
- $282
- Section 301 tariff (25.0%)
- $2,014
- Customs fees (MPF/HMF)
- $43
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: Plastic
- Size: 140*38
- Color: black
- Material: Other
- Certification: CEOther
- Usage: HouseholdOtherIndustrial
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
About this product
- Materials: Plastic
- Size: 140*38
- Color: black
- Material: Other
- Certification: CEOther
- Usage: HouseholdOtherIndustrial
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
Product details
| Materials | Plastic |
|---|---|
| Size | 140*38 |
| Color | black |
| Material | Other |
| Certification | CEOther |
| Usage | HouseholdOtherIndustrial |
| IP rating | IP65 |
| Customized | Customized |
Product details
| Materials | Plastic |
|---|---|
| Size | 140*38 |
| Color | black |
| Material | Other |
| Certification | CEOther |
| Usage | HouseholdOtherIndustrial |
| IP rating | IP65 |
| Customized | Customized |
From the supplier
LFM3 Series differential pressure gauge use imported high precision sensor and digitalization technology.
They are easy installation, LCD display, clear and accurate reading, and can be applied to measure fan and blower pressures, filter resistance, air velocity, furnace draft, pressure drop across orifice plates and medical care equipment.
This series has three optional discrete output versions (relay, NPN and PNP), can be flexibly applied to control the external equipments.
Features
Non-polar Input: No need to differentiate the negative or positive input voltage sourcing lead
Excellent Material: housing made of FR-ABS, satisfactory impact resistance and heat resistance etc.
Span: 0~±100Pa/0~±1,000Pa / 0~±10,000Pa Accuracy: ±1.0%FS
Various switchable pressure units
Big LCD screen
Manual button of zero calibration
Manual button of default reset
Max. and min pressure value to review
Settable response time
Built-in buzzer with sound-light alarm, field programmable alarm pressure value.
Imported chip
The Max. and Min. pressure range of discrete output can be set (only LFM32 Series)
Specification
Accuracy
±1.0%FS
Unit
Pa, KPa, mBar, mmHG, inWC, mmWC,
Consumption
≤ 0.75W
Fluid
Air or neutral fluid
Operation Temperature
-10~+60°C
Storage Temperature
- 10~+70°C
Allowable Overload Pressure
Range
Overload Capacity
-1000~+1000Pa
-15,000~+15,000Pa
-10,000~+10,000Pa
-150,000~+150,000Pa
-100~+100Pa
-4500~+4500Pa
From the supplier
LFM3 Series differential pressure gauge use imported high precision sensor and digitalization technology.
They are easy installation, LCD display, clear and accurate reading, and can be applied to measure fan and blower pressures, filter resistance, air velocity, furnace draft, pressure drop across orifice plates and medical care equipment.
This series has three optional discrete output versions (relay, NPN and PNP), can be flexibly applied to control the external equipments.
Features
Non-polar Input: No need to differentiate the negative or positive input voltage sourcing lead
Excellent Material: housing made of FR-ABS, satisfactory impact resistance and heat resistance etc.
Span: 0~±100Pa/0~±1,000Pa / 0~±10,000Pa Accuracy: ±1.0%FS
Various switchable pressure units
Big LCD screen
Manual button of zero calibration
Manual button of default reset
Max. and min pressure value to review
Settable response time
Built-in buzzer with sound-light alarm, field programmable alarm pressure value.
Imported chip
The Max. and Min. pressure range of discrete output can be set (only LFM32 Series)
Specification
Accuracy
±1.0%FS
Unit
Pa, KPa, mBar, mmHG, inWC, mmWC,
Consumption
≤ 0.75W
Fluid
Air or neutral fluid
Operation Temperature
-10~+60°C
Storage Temperature
- 10~+70°C
Allowable Overload Pressure
Range
Overload Capacity
-1000~+1000Pa
-15,000~+15,000Pa
-10,000~+10,000Pa
-150,000~+150,000Pa
-100~+100Pa
-4500~+4500Pa
