About this product
- Materials: Cast iron, steel, electrical components, etc.
- Size: 2520*2100*2500
- Color: Custom color
- Exports to: Mainland China, Middle East, Southeast Asia, South Asia, Russia, EU
- Made in: Shandong, China
About this product
- Materials: Cast iron, steel, electrical components, etc.
- Size: 2520*2100*2500
- Color: Custom color
- Exports to: Mainland China, Middle East, Southeast Asia, South Asia, Russia, EU
- Made in: Shandong, China
Product details
| Materials | Cast iron, steel, electrical components, etc. |
|---|---|
| Size | 2520*2100*2500 |
| Color | Custom color |
Product details
| Materials | Cast iron, steel, electrical components, etc. |
|---|---|
| Size | 2520*2100*2500 |
| Color | Custom color |
From the supplier
XL6336 XL6336C XL6336CL universal milling machine
It is a new series of conventional machines equipped with servo motors and drives for 3 working feeds,
which is a patented product of our factory:
Main Features :
1.Rotary table can be ordered at special request
2.XYZ 3-axis auto-feed and fast feed by servo motor
3.Taiwan 5hp /7.5HP step/variable turret milling head
Specification
Specifications
Unit
XL6336
XL6336C
XL6336CL
Table size
mm
1325×360
1600×360
Table travel (X/Y/Z)
mm
750/320/460
1100/320/450
1300/320/450
Table feed. (X/Y/Z)
mm/min
30-750/20-500/15-375
Table rapid speed (X/Y/Z)
mm/min
1200/800/600
Spindle taper
7: 24 IS050 (H) Horizontal; 7: 24 IS040 (V) Vertical
Stroke of spindle quill
mm
127 (V)
Distance between spindle nose and table surface
mm
200-660
200-650
Distance between horizontal spindle center line and table surface
mm
20-480
20-470
Distance between horizontal spindle center line and arm surface
mm
245
Spindle speed range
r.p.m
12-Level Steps 60-1800 (H) Lying, 16-Level Steps 65~4660 (V) Standing
T-slots(NO./width/pitch)
mm
3/18/80
Arm travel
mm
550
Main motor power
Kw
5.5 (H) Horizontal, 3.7 (V) Vertical
Torque of X/Y/Z axis AC servo motor
N.m
10
Overall size
mm
1800×2100×2500
2245×2100×2500
2520×2100×2500
Net weight
kg
2710
2780
2850
From the supplier
XL6336 XL6336C XL6336CL universal milling machine
It is a new series of conventional machines equipped with servo motors and drives for 3 working feeds,
which is a patented product of our factory:
Main Features :
1.Rotary table can be ordered at special request
2.XYZ 3-axis auto-feed and fast feed by servo motor
3.Taiwan 5hp /7.5HP step/variable turret milling head
Specification
Specifications
Unit
XL6336
XL6336C
XL6336CL
Table size
mm
1325×360
1600×360
Table travel (X/Y/Z)
mm
750/320/460
1100/320/450
1300/320/450
Table feed. (X/Y/Z)
mm/min
30-750/20-500/15-375
Table rapid speed (X/Y/Z)
mm/min
1200/800/600
Spindle taper
7: 24 IS050 (H) Horizontal; 7: 24 IS040 (V) Vertical
Stroke of spindle quill
mm
127 (V)
Distance between spindle nose and table surface
mm
200-660
200-650
Distance between horizontal spindle center line and table surface
mm
20-480
20-470
Distance between horizontal spindle center line and arm surface
mm
245
Spindle speed range
r.p.m
12-Level Steps 60-1800 (H) Lying, 16-Level Steps 65~4660 (V) Standing
T-slots(NO./width/pitch)
mm
3/18/80
Arm travel
mm
550
Main motor power
Kw
5.5 (H) Horizontal, 3.7 (V) Vertical
Torque of X/Y/Z axis AC servo motor
N.m
10
Overall size
mm
1800×2100×2500
2245×2100×2500
2520×2100×2500
Net weight
kg
2710
2780
2850
