About this product
- Materials: Metal
- Size: 3000*1180*1850
- Color: blue
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
About this product
- Materials: Metal
- Size: 3000*1180*1850
- Color: blue
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
Product details
| Materials | Metal |
|---|---|
| Size | 3000*1180*1850 |
| Color | blue |
From the supplier
Introduce：
It is an automatic environmental machine with multi-running positions. It runs a whole procedure of paper-feeding, cup-fan-wall sealing, oiling, bottom punching, heating, rolling, rimming, rounding and tripping. It is an ideal equipment of producing drinking cups, ice cream cups and other food cone-shaping containers. YZDS-A12 is with heater sealing; YZDS-B12 is with ultrasonic sealing. This type paper cup machine is mainly used to making one side or two side PE coated paper cups from 2 oz to 14 oz, But if you ask for bigger cups, over 16oz,will need model YZDS-L16/L22.
Technical parameter：
Model Name
YZDS-A12
YZDS-B12
YZDS-L16
Suitable Size
2oz-14oz
2-14oz
8-16oz; >16oz
Raw Material
150-280gsm single side PE coated paper
1150-400gsm single/double side PE coated paper, PLA paper
Capacity
45-60pcs/min
40-50pcs/min
Total Power
3.8KW
4.0-6.0kw
5.0-7.0kw
Air Flow Air Pressure
/
/
>0.6Mpa
0.4-0.8m3/min
N.W./G.W.
1300kg/1400kg
1300kg/1400kg
1300kg/1400kg
Electric Power
220v, single phase, 50Hz; 380v, three phase, 50Hz; Contact supplier for other type
Overall Dimension
YZDS-A12:
2600L*1160W*1600H(mm)
YZDS-B12:
2620L*1160W*1650H(mm)
YZDS-L16:
16oz---2780L*1180W*1750H(mm)
22oz---2840L*1180W*1840H(mm)
24oz---3000L*1180W*1850H(mm)
