About this product
- Materials: steel
- Size: 8200*3100*1870
- Color: red+white
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
About this product
- Materials: steel
- Size: 8200*3100*1870
- Color: red+white
- Exports to: Mainland China, Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
Product details
| Materials | steel |
|---|---|
| Size | 8200*3100*1870 |
| Color | red+white |
From the supplier
- Product detailsFeature4 functionsSolid state relayFOTEK from TaiwanCylinderSHAKO TaiwanInverterYasakwa JapanTouch screenWeinview TaiwanPLCPanasonic JanpanServo motorYasakwa JapanMain motorCPG TaiwanPhotocellSICK Germany
Functions and Features:
This is a multifunctional machine combining CHOVYTING CW-800LP fully automatic soft loop handle bag making machine, CW-800SP fully automatic patch handle bag making machine and CW-800PD fully automatic draw string handle bag making machine. It is the best choice for increased capacity and space-saving benefits.
It’s user friendly ergonomic design, rigid construction with resistant to vibration
Recipe and production control system with special PLC system,
Easy changeable single and double sealing bar systemFEATURES:
-With soft loop handle bag function
-With patch handle bag function
-With poly draw handle bag function
-With die cut handle bag functionProduct Specifications:
ModelCW-800ZDCW-800LPCW-800SPCW-800PDLength of bag-making(Height of bag)250-750mm250-750mm250-750mm250-750mmWidth of bag-making250-600mm250-600mm250-600mm250-600mmTop-folding edge50-75mm50-75mm50-75mm50-75mmBottom gusset20-70mm20-70mm20-70mm20-70mmSpeed of bag-making Soft loop handle bag60pcs/min60pcs/min Patch handle bag60pcs/min 60pcs/min Poly draw handle bag65pcs/min 65pcs/minDie cut handle bag80pcs/min80pcs/min80pcs/min Total power13KW10KW10KW10KWMachine weight3500kg3200kg3200kg3200kgMachine dimension
(L*W*H)
8200*3100*1870mm8200*3100*1870mm8200*3100*1870mm8200*3100*1870mmAir compressor
(not included)
6HP6HP6HP6HPApplication Fields:
Shopping bags with loop handle, patch handle and Die cut handle deigns are widely used in super market, shopping mall etc. Draw tape handle bag with draw string inserting is widely used in hotel laundry and garbage refuse collection.
Multifunctional model CW-800ZD highly enhances production variety, reduces production cost and allows the buyer to try and gain a significant margin of profit in the market.
Sample Bags:
