LC1-D80 80A 3P+NO+NC types of contactor
SHANGHAI CET ELECTRIC CO., LTD
See what’s includedHide breakdown
- FOB goods (100)
- $700
- Ocean freight + handling (0.30 CBM)
- $820
- US duty (2.7%)
- $19
- Section 301 tariff (25.0%)
- $175
- Customs fees (MPF/HMF)
- $34
Estimate in USD to a US port using category averages (HTS 8536/8504/8507), rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- FOB goods (100)
- $700
- Ocean freight + handling (0.30 CBM)
- $820
- US duty (2.7%)
- $19
- Section 301 tariff (25.0%)
- $175
- Customs fees (MPF/HMF)
- $34
Estimate in USD to a US port using category averages (HTS 8536/8504/8507), rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
LC1-D80 80A 3P+NO+NC types of contactor
SHANGHAI CET ELECTRIC CO., LTDSee what’s includedHide breakdown
- FOB goods (100)
- $700
- Ocean freight + handling (0.30 CBM)
- $820
- US duty (2.7%)
- $19
- Section 301 tariff (25.0%)
- $175
- Customs fees (MPF/HMF)
- $34
Estimate in USD to a US port using category averages (HTS 8536/8504/8507), rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- FOB goods (100)
- $700
- Ocean freight + handling (0.30 CBM)
- $820
- US duty (2.7%)
- $19
- Section 301 tariff (25.0%)
- $175
- Customs fees (MPF/HMF)
- $34
Estimate in USD to a US port using category averages (HTS 8536/8504/8507), rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: AL+PC
- Size: 47x76x85
- Color: Black
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
About this product
- Materials: AL+PC
- Size: 47x76x85
- Color: Black
- Exports to: Africa, Middle East, Southeast Asia, South Asia, Central Asia, USA and Canada, Latin America, Russia, EU, Other European Countries, Japan and South Korea, Hong Kong China, Macao China and Taiwan China, Others
- Made in: Zhejiang, China
Product details
| Materials | AL+PC |
|---|---|
| Size | 47x76x85 |
| Color | Black |
Product details
| Materials | AL+PC |
|---|---|
| Size | 47x76x85 |
| Color | Black |
From the supplier
CJX2-D(LC1-D) series AC contatcor is suitable for using in the circuits up to the rated voltage 660V AC 50Hz or 60Hz,rated current up to 620A,for making,breaking,frequently starting & controlling the AC contactor.Combined with the auxiliary contact block,timer delay & machine-interlocking device etc,it become the delay contactor,mechanical interlocking contactor,start-delta starter.With the termal delay,it is combined into the electromagnetic starter.The products comply with IEC60947-4.
Model: LC1-D80
Rated current: 80A
Poles: 3 + 1
Brand: SHCET or OEM
Main components: coil, iron core, return spring, contact system and armature, etc.
Three attributes of AC contactors:
1. AC contactor coil. The coil is usually marked with A1 and A2, which can be simply divided into AC contactors and DC contactors. We often use AC contactors, of which 220 / 380V is the most commonly used.
2. Main contact of AC contactor. L1-L2-L3 is connected to the three-phase power inlet, and T1–T2-T3 is connected to the power outlet, which can be used to connect the load line. The main contacts of the AC contactor are normally open contacts, which are mainly connected in the main circuit to control the start and stop of motors and other equipment!
3. Auxiliary contact of AC contactor. Auxiliary contacts can be divided into normally open point NO and normally closed point NC.
3-1 Normally open point NO, under normal circumstances, normally open point NO is mainly used for contactor self-locking control and transmission of running signals, for example: AC contactor normally open point NO connected to a red indicator light can be used as motor operation The indicator light, when the AC contactor is energized, the normally open point NO is closed, and the indicator light is turned on to transmit the running signal of the motor or circuit.
3-2 Normally closed point NC of AC contactor. Under normal circumstances, the normally closed point NC of the AC contactor is mainly used for circuit interlocking and signal transmission. For example: the NC contactor normally closed point NC is connected with a green indicator light, which can be used as a stop indicator for the circuit or the motor. When the AC contactor is energized, the normally closed point NC is disconnected, the stop indicator light is off, and the corresponding operation indicator light , The circuit is running.
LC1-D AC ContactorStandardIEC/EN 60947-4-1ProductContactorModel Rated Current(A)Standard Power Ratings of 3-phase motors in AC-3(KW)Electrical Life AC3(x10x4)Mechanical Life AC3(x10x4)Number of the Contacts
220/230V380/400V415V500V660/690V
LC1-D099A2.2445.55.510010003P+NO; 3P+NCLC1-D1212A35.55.57.57.51001000LC1-D1818A47.5910101001000LC1-D2525A5.5111115151001000LC1-D3232A7.5151518.518.580800LC1-D4040A1118.5222230808003P+NO+NCLC1-D5050A152225303360800LC1-D6565A18.53037373760800LC1-D8080A223745554560600LC1-D9595A254545555560600
From the supplier
CJX2-D(LC1-D) series AC contatcor is suitable for using in the circuits up to the rated voltage 660V AC 50Hz or 60Hz,rated current up to 620A,for making,breaking,frequently starting & controlling the AC contactor.Combined with the auxiliary contact block,timer delay & machine-interlocking device etc,it become the delay contactor,mechanical interlocking contactor,start-delta starter.With the termal delay,it is combined into the electromagnetic starter.The products comply with IEC60947-4.
Model: LC1-D80
Rated current: 80A
Poles: 3 + 1
Brand: SHCET or OEM
Main components: coil, iron core, return spring, contact system and armature, etc.
Three attributes of AC contactors:
1. AC contactor coil. The coil is usually marked with A1 and A2, which can be simply divided into AC contactors and DC contactors. We often use AC contactors, of which 220 / 380V is the most commonly used.
2. Main contact of AC contactor. L1-L2-L3 is connected to the three-phase power inlet, and T1–T2-T3 is connected to the power outlet, which can be used to connect the load line. The main contacts of the AC contactor are normally open contacts, which are mainly connected in the main circuit to control the start and stop of motors and other equipment!
3. Auxiliary contact of AC contactor. Auxiliary contacts can be divided into normally open point NO and normally closed point NC.
3-1 Normally open point NO, under normal circumstances, normally open point NO is mainly used for contactor self-locking control and transmission of running signals, for example: AC contactor normally open point NO connected to a red indicator light can be used as motor operation The indicator light, when the AC contactor is energized, the normally open point NO is closed, and the indicator light is turned on to transmit the running signal of the motor or circuit.
3-2 Normally closed point NC of AC contactor. Under normal circumstances, the normally closed point NC of the AC contactor is mainly used for circuit interlocking and signal transmission. For example: the NC contactor normally closed point NC is connected with a green indicator light, which can be used as a stop indicator for the circuit or the motor. When the AC contactor is energized, the normally closed point NC is disconnected, the stop indicator light is off, and the corresponding operation indicator light , The circuit is running.
LC1-D AC ContactorStandardIEC/EN 60947-4-1ProductContactorModel Rated Current(A)Standard Power Ratings of 3-phase motors in AC-3(KW)Electrical Life AC3(x10x4)Mechanical Life AC3(x10x4)Number of the Contacts
220/230V380/400V415V500V660/690V
LC1-D099A2.2445.55.510010003P+NO; 3P+NCLC1-D1212A35.55.57.57.51001000LC1-D1818A47.5910101001000LC1-D2525A5.5111115151001000LC1-D3232A7.5151518.518.580800LC1-D4040A1118.5222230808003P+NO+NCLC1-D5050A152225303360800LC1-D6565A18.53037373760800LC1-D8080A223745554560600LC1-D9595A254545555560600
