Xlk5036 Xlk5030 CNC Vertical Knee Type Milling Machine
TENGZHOU XILI MACHINE TOOL CO.,LTD.
See what’s includedHide breakdown
- FOB goods (100)
- $1,100,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $38,500
- Section 301 tariff (25.0%)
- $275,000
- Customs fees (MPF/HMF)
- $2,010
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- FOB goods (100)
- $1,100,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $38,500
- Section 301 tariff (25.0%)
- $275,000
- Customs fees (MPF/HMF)
- $2,010
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
Xlk5036 Xlk5030 CNC Vertical Knee Type Milling Machine
TENGZHOU XILI MACHINE TOOL CO.,LTD.See what’s includedHide breakdown
- FOB goods (100)
- $1,100,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $38,500
- Section 301 tariff (25.0%)
- $275,000
- Customs fees (MPF/HMF)
- $2,010
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
- FOB goods (100)
- $1,100,000
- Ocean freight + handling (5.0 CBM, volume guessed from price)
- $1,300
- US duty (3.5%)
- $38,500
- Section 301 tariff (25.0%)
- $275,000
- Customs fees (MPF/HMF)
- $2,010
Estimate in USD to a US port using category averages, rates as of 2026-09. Other countries on request. A quote from our desk uses real carton sizes, freight and the exact tariff line.
Verify from $29 · written report in 3 business days · 100% refund if not satisfied
About this product
- Materials: Cast iron, steel, electrical components, etc.
- Size: 2245*2100*2150mm
- Color: Custom color
- Exports to: Mainland China, Middle East, Southeast Asia, South Asia, Russia, EU
- Made in: Shandong, China
About this product
- Materials: Cast iron, steel, electrical components, etc.
- Size: 2245*2100*2150mm
- Color: Custom color
- Exports to: Mainland China, Middle East, Southeast Asia, South Asia, Russia, EU
- Made in: Shandong, China
Product details
| Materials | Cast iron, steel, electrical components, etc. |
|---|---|
| Size | 2245*2100*2150mm |
| Color | Custom color |
Product details
| Materials | Cast iron, steel, electrical components, etc. |
|---|---|
| Size | 2245*2100*2150mm |
| Color | Custom color |
From the supplier
Machine Equipment :
Standard equipment :SIEMENS808D
Optional equipment:1.The fourth axis CNC rotary table
2.CNC dividing head
Optional CNC System:FANUC /Mitsubishi/GSK 980MDC System
Specification :
Specification
Unit
XLK5030
Table size
mm
1370X300
Table Travel (X/Y/Z)
mm
820/300/400
Spindle nose to work surface
mm
35-435
Spindle hole taper
---
7:24 ISO40
Rapid speed of table (X/Y/Z)
mm/min
4000/4000/3000
T-slots(No./Width/Pitch)
mm
3/14/80
Spindle speed range
r/min
12 35-1500
Stroke of spindle quill
mm
70
Distance between spindle axis and column guideway
mm
285
Swivel angle of Vertical milling head
---
±30°
Main motor power
kw
3
Torque of X/Y/Z axis AC servo motor
N.m
7.7/7.7/15
Overall size
mm
1850X1680X1900
Net weight
kg
1850
Company information:
Tengzhou Xili Machine Tool Co., Ltd. and Shandong Yourong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We have more than 20 years manufacturer experience. Our main products include CNC Machining Center, CNC Gantry Milling Machine,vertical milling machines, horizontal milling machines, universal milling machines, planer type milling machines, ram type milling machines and vertical drilling machines with all 30 categories.
We are manufacturer.All our products passed CE, ISO9001. You can trust our quality and service.
Hope we can built long-term business relationship with you.
From the supplier
Machine Equipment :
Standard equipment :SIEMENS808D
Optional equipment:1.The fourth axis CNC rotary table
2.CNC dividing head
Optional CNC System:FANUC /Mitsubishi/GSK 980MDC System
Specification :
Specification
Unit
XLK5030
Table size
mm
1370X300
Table Travel (X/Y/Z)
mm
820/300/400
Spindle nose to work surface
mm
35-435
Spindle hole taper
---
7:24 ISO40
Rapid speed of table (X/Y/Z)
mm/min
4000/4000/3000
T-slots(No./Width/Pitch)
mm
3/14/80
Spindle speed range
r/min
12 35-1500
Stroke of spindle quill
mm
70
Distance between spindle axis and column guideway
mm
285
Swivel angle of Vertical milling head
---
±30°
Main motor power
kw
3
Torque of X/Y/Z axis AC servo motor
N.m
7.7/7.7/15
Overall size
mm
1850X1680X1900
Net weight
kg
1850
Company information:
Tengzhou Xili Machine Tool Co., Ltd. and Shandong Yourong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We have more than 20 years manufacturer experience. Our main products include CNC Machining Center, CNC Gantry Milling Machine,vertical milling machines, horizontal milling machines, universal milling machines, planer type milling machines, ram type milling machines and vertical drilling machines with all 30 categories.
We are manufacturer.All our products passed CE, ISO9001. You can trust our quality and service.
Hope we can built long-term business relationship with you.
About the supplier
Main products: Miller,CNC Machining center,Drilling machine
- ✓Exhibited at 10 of the last 10 Canton Fairs
- ✓Manufacturer
- ✓Founded 1999
Manufacturing exhibitors show in Phase 1 of the Canton Fair, 15 to 19 October 2026.
- Exhibited at 10 of the last 10 Canton Fairs
- Manufacturer
- Founded 1999
