Genset working condition:

lAcceptable working conditions:
Ambient temperature : -10°C~+40°C
(antifreeze and water heater needed for below 0°C)
Relative humidity:Altitude:≤ 500m

l Normal working conditions:
Genset can run at rated power on the conditions:
Atmospheric Pressure: 100kPa, Ambient Temp: 20°C, Relative Humidity: 30%.

lApplied gas:
Natural Gas, Biogas, LPG, Landfill gas, Oil gas, Syngas, Coal mine gas
Acceptable fuel gas pressure: 8~12kPa

CH4 content: for natural gas≥85% CH4 content: for biogas≥55%
Gas heat value≥5500kcal/Nm3 (23MJ/Nm3 ). Genset output power will increase as the gas heat value increase, if use low heat value gas for fuel(Heat valueGas doesn't include free water or free materials (the size of impurities should be less than 5μm.)
H2S content≤200mg/Nm3
NH3 content≤20mg/Nm3
Impurities content≤30mg/Nm3;size≤5μm
Water content≤40g/Nm3, no free water.

NATURAL GAS generator Set

Technical Data





Genset ModelPrime Power (KW/KVA)Engine ModelClylindersBore×Stroke (mm)Gas Consumption Rate (m3/kw.h)Displacement (L)KWKVANG2-30KW3037.51004NG4100×1270.5-0.33.99NG2-40KW40501006NG6100×1270.5-0.35.98NG2-90KW90112.51006-G6TAG6100×1270.5-0.35.98NG2-100KW100110R6156126×1300.5-0.39.7NG2-120KW120132R6156126×1300.5-0.39.7NG2-150KW150165R6186126×1500.5-0.311.2NG2-160KW160200D116128×1420.5-0.310.96NG2-220KW220275D158128×1420.5-0.314.62NG2-320KW320400D2212128×1420.5-0.321.93NG2-440KW440500D3016128×1420.5-0.329.24

2.Genset working condition :

ACCEPTABLE WORKING CONDITIONS:
Ambient temperature : -40°C~+45°C (antifreeze or hot water needed for below -20°C)
Relative humidity:Altitude:≤1000mNORMAL WORKING CONDITIONS:
Genset can run at rated power on the conditions:
Atmospheric Pressure: 100kPa Ambient Temp: 20°CRelative Humidity30%.APPLIED GAS:Natural Gas, Biogas,Oil field gasAcceptable gas pipeline pressure:0.8~450kPaEngine inlet pressure: 0.8~5.0kPa (80~500mmH2O) CH4 content:for natural gas ≥75%; for biogas≥40%Sulphur content:≤400ppmGas heat value:≥5500kcal/Nm3 (23MJ/Nm3 )Genset output power will increase as the gas heat value increase, if use low heat value gas for fuel(Heat value


3 Standard Scope of Supply:
