HEBEI METALS & MINERALS CORP.LTD.

TEL: +8631185202796

FAX:+8631187044131

EMAIL:

hbmetals@hebminmetals.com.cn

CHECK  VALVE       SWING  TYPE







TESTS

HYDRAULIC TEST ACC TO BS5153

SEAT:1.1XPN.BODY:1.5 XPN OPERATINGtorque test.

DESSIGN&MANUFACTURESTANDARD

BS5153/PN16





\n \n



\n \n \n \n

APPLICABLE  STANDARDS

1.FLANGE DRILLEDACC. TO                     TOBS4504-2000

2.FACE TO FACE DIMENSIONACC.TO             TOBS1873-1975

3.FLANGE                               RAISED FACE FLANGE

4.MAXIMUM WORKING PRESSURE               16BAR(1.6mpa)

5. MAXIMUM WORKING TEMPERATURE                    120℃



MATERIAL LIST

1.BODY :                                     GREY CAST IRON

2.BONNET:                                   GREY CAST IRON

3.DISC :                                      GREY CAST IRON

4.ARM HINGE:                                GREY CAST IRON

5.HINGE PIN :                                STAINLESS STEEL

6. HINGE PIN :                               STAINLESS STEEL

7. BODY  SEAL  RING:                        CAST BRASS

.  DISC  SEAL       RING:                        CAST BRASS

8. SEAL  RING :                               O-RING NBR

9. Bolt                                        CARBON  STEEL



Dimensions                                                                        Unit:mm

SIZE

H

BS5153 PN16

L

D

Z-фd

P.C.D

in.2(50mm)

118

203

165

4-18

125

in.2½ (65mm)

138

216

185

4-18

145

in.3(80mm)

148

241

200

8-18

160

in.4(100mm)

180

292

220

8-18

180

in.5(125mm)

208









in.6(150mm)

228

406

285

8-22

240

in.8(200mm)

258

495

340

12-22

295

in.10(250mm)

388

622

405

12-26

355

in.12(300mm)

428

698

460

12-26

410





"}
